Solution Configurations Archives - ESRD https://www.esrd.com/product-tag/solution-configurations/ Engineering Software Research and Development, Inc. Thu, 22 Jun 2023 15:48:10 +0000 en-US hourly 1 https://wordpress.org/?v=6.6.2 https://www.esrd.com/wp-content/uploads/cropped-SC_mark_LG72ppi-32x32.jpg Solution Configurations Archives - ESRD https://www.esrd.com/product-tag/solution-configurations/ 32 32 ASIP 2022 Training – Best Practices for the Modeling and Analysis of Bonded Doubler Repairs https://www.esrd.com/resource-library/product/asip-2022-training-best-practices-for-the-modeling-and-analysis-of-bonded-doubler-repairs/ Mon, 05 Dec 2022 15:01:02 +0000 https://www.esrd.com/?post_type=product&p=26512 Abstract: this 2-hour training course, originally presented at the ASIP 2022 conference in Phoenix, AZ, explored the following topics:
  • StressCheck’s FEA technology implementation enabling modeling of very thin domains, including adhesive layers with 3D-solid elements.
  • Best practices and guidelines for modeling and analyzing 3D bonded repair doubler variations (e.g. racetrack/rectangular, circular/elliptical, tapered, metallic, ply-by-ply, homogenized, etc.) for circular cutouts and grindouts.
  • Performing “what if?” logic-driven studies of a digital 3D bonded repair handbook solution via StressCheck API-powered Engineering Simulation App, in which user-defined input data is passed from Python or Excel VBA to StressCheck Professional to perform scripted “on-the-fly” model adjustments and repair-oriented computations.
]]>
You need to be logged in to view this content. Please Log in. Not a member? Register.
]]> StressCheck Tutorial: Incorporating CX Residual Stresses in SIF and J-integral Extractions https://www.esrd.com/resource-library/product/stresscheck-tutorial-incorporating-cx-residual-stresses-in-sif-and-j-integral-extractions/ Thu, 14 Jul 2022 01:21:28 +0000 https://www.esrd.com/?post_type=product&p=25522 Abstract: incorporating coldworked (CX) residual stresses in the computation of fracture mechanics parameters (SIF/J-integral). The following workflow is outlined:
  1. Open existing 3D-Fracture Handbook model (CrackOpenHole-ResidualStresses.scw)
  2. Add parameters, convert material to elastic-plastic, and modify the model boundary conditions for a cold-work simulation
  3. Solve a linear solution, and then solve the cold-work simulation events via incremental plasticity
  4. Use BRS mapping to map the cold-work solution to a new part
  5. Assign BRS load and remote traction, convert material to linear-elastic, and modify constraints to represent the crack face
  6. Solve a linear analysis and extract SIF's/J-integrals
]]>
You need to be logged in to view this content. Please Log in. Not a member? Register.
]]> StressCheck Tutorial: Filled vs Open Hole SIF Comparison for 3D Offset Hole https://www.esrd.com/resource-library/product/stresscheck-tutorial-filled-vs-open-hole-sif-comparison-for-3d-offset-hole/ Tue, 16 Nov 2021 16:38:35 +0000 https://www.esrd.com/?post_type=product&p=23280 Abstract: comparison of 3D part-thru crack stress intensity factor (SIF) distributions for filled (pin-propped) vs open (bearing-loaded) offset holes. Simultaneous solution and extractions based on Parts and Solution Configurations.]]>
You need to be logged in to view this content. Please Log in. Not a member? Register.
]]> StressCheck Tutorial: 2D Bearing + Bypass Loaded Plate – Filled vs Open Offset Hole SIF’s https://www.esrd.com/resource-library/product/stresscheck-tutorial-2d-bearing-bypass-loaded-plate-filled-vs-open-offset-hole-sif/ Wed, 26 Dec 2018 19:18:28 +0000 https://esrd.com/?post_type=product&p=8754 Abstract: Using Parts and Solution Configurations to compare 2D thru-crack stress intensity factors, or SIF's, for filled and open hole bearing + bypass loaded plate configurations. The hole location is offset from the right edge of the plate, and a crack edge is defined at the right edge of the hole. The filled hole solution configuration solves a loaded fastener element in the offset hole, while the open hole solution configuration solves a bearing load distribution in the offset hole. General nonlinear analyses are performed for both solution configurations, and crack tip SIF's are extracted from the NLGen solutions using the Fracture Mechanics module.]]>
You need to be logged in to view this content. Please Log in. Not a member? Register.
]]> StressCheck Tutorial: Parts and Solution Configurations Part 1 – Planar + Hand Mesh https://www.esrd.com/resource-library/product/stresscheck-tutorial-parts-and-solution-configurations-part-1-planar-hand-mesh/ Fri, 14 Dec 2018 14:12:18 +0000 https://esrd.com/?post_type=product&p=8632 Abstract: Planar analysis of hand meshed lug with and without a bushing, in which Parts and Solution Configurations are used to unlock in-session comparisons of the lug with self-equilibrated loading vs. the lug + bushing with a spring constraint.]]>
You need to be logged in to view this content. Please Log in. Not a member? Register.
]]> StressCheck Tutorial: Parts and Solution Configurations Part 2 – 3D + Automesh https://www.esrd.com/resource-library/product/stresscheck-tutorial-parts-and-solution-configurations-part-2-3d-automesh/ Fri, 14 Dec 2018 13:56:43 +0000 https://esrd.com/?post_type=product&p=8629 Abstract: 3D solid modeling and automeshing of a plate with hole and neat-fit pin, in which Parts and Solution Configurations are used to unlock in-session comparisons of propped hole (multi-body contact) vs. open hole stress concentration factors (Kt's). A continuation of StressCheck Tutorial: Parts and Solution Configurations Part 1 - Planar + Hand Mesh.]]>
You need to be logged in to view this content. Please Log in. Not a member? Register.
]]>
