Helpful Hints and Tips: Using the 3-2-1 Rigid Body Constraint Approach
Abstract: This presentation demonstrates the 3-2-1 rigid body constraint approach as described by Tony Abbey’s article “Free-Floating FEA Models” in Digital Engineering. Free-floating is self-equilibrated under the applied load.
Categories: StressCheck Core, StressCheck Professional. Tags: Boundary Conditions, Detailed Stress, Material Properties, Meshing, Results.
