Getting started with StressCheck products not only includes learning an intuitive GUI layout, an hierarchic solver implementation and advanced live results processing features, but also grasping how (and why) ESRD’s unique approach to numerical simulation differs from traditional finite element modeling practices. With the steps outlined in the following Quick Start Guide, you’ll be well on your way to becoming a StressCheck expert.
Quick Start Guide
Are you or your team interested in a formal StressCheck training course to speed up the onboarding process? Visit our Training page to learn more about the available StressCheck training options.
Recommended Actions & Resources
The following tabs provide an intuitive sequence of actions, tips, demos and links that will lead you to becoming productive and successful with StressCheck Professional sooner than later.
In order to get started with StressCheck or other ESRD software products, you must first register for an ESRD membership. We will review your registration based on your organization’s SM&TS contract status (if identifiable) and assign you an appropriate membership level.
Download the appropriate ESRD software product:
Install the ESRD software product, and then provide ESRD Support with the local machine OR license server details. Once the license request is received and processed, we will generate your license and e-mail it to you in the form of a .dat file. You can then setup the software to run on client machines.
Get Disk or HOST ID and Send to ESRD Support
There are two types of licensing models: Node-Locked (single user) or Floating (concurrent users with a license server connection). Determine the appropriate licensing model for your organization and then obtain the Disk or HOST ID.
Floating License Model? You'll Need FlexNet Publisher
ESRD software products use Revenera’s FlexNet Publisher v11.19.5 for license administration, so it may be necessary to set up (or modify an existing) FlexNet license server if you have a floating (concurrent) license model.
On Startup
When ESRD software products are started for the first time, they ask to point to either a copy of the license file OR a server name and port number. Either option is acceptable for the floating (concurrent) license model.
Having Issues?
To get started with StressCheck products, we recommend first watching this 9 minute “StressCheck User Interface Walkthrough” video. It will provide the basics of key GUI elements and software navigation:
Next, watch a 13-minute video describing the improvements and updates to the StressCheck v11 graphical user interface (GUI) experience, including extensive layout customization features, lockscreens for loading/saving/solution progress, a semi-automatic file upgrade utility, and general workflow guidelines.
Then, watch a 12-minute video of the practical tutorial outlined in the StressCheck v11 Getting Started Guide. This video will provide the basics of performing a 3D elasticity analysis with StressCheck, including 3D solid geometry importation, automeshing, materials & boundary conditions, linear p-extensions and “live” dynamic results processing:
More resources for getting started with StressCheck Professional’s usage, features and applications may be found in the following links:
- For an overview of the StressCheck GUI layout, features and workflows, refer to the StressCheck Professional Getting Started Guide.
- For the full StressCheck documentation, refer to our StressCheck Documentation.
- For a playlist of helpful e-Learning tutorial videos, refer to Getting Started with StressCheck: e-Learning Video Showcase.
- For a broad list of foundational StressCheck topics, visit the StressCheck Basics section of our Resource Library.
- For StressCheck software FAQ’s, refer to our Software FAQ’s knowledge base.
Need Additional Support?
Please let us know if you are having any difficulties with StressCheck Professional installation, licensing or software usage by completing our Request for ESRD Support form.
